Superior Stability and Durability with GR6-67D-A Wire Rope Vibration Isolator
Key Features
- Easy to install with no specialized tools required
- Stainless steel construction for durability in all climates
- Modular design for easy maintenance and component replacement
- Excellent shock and vibration resistance
- Up to 90% vibration isolation efficiency
Technical Specifications
| Attribute |
Value |
| Shock And Vibration Resistance |
Excellent |
| Max Static Load |
20-47N (2kg-4.8Kg) |
| Vibration Isolation |
Up to 90% |
| Isolation Frequency |
10Hz |
| Natural Frequency |
7Hz-15Hz |
| Mounting Orientation |
Vertical |
| Axial Stiffness |
50N/mm |
| Installation |
Wall Mounted |
| Vibration Isolation Type |
Passive |
| Vibration Frequency Range |
10Hz to 100Hz |
| Mounting Type |
Threaded Stud |
| Shock Resistance |
30g/11ms - 40g/11ms |
Product Description
GR6 Series isolators effectively eliminate both small rhythmic vibrations during travel shots and sudden, intense vibrations from rough terrain. This stability is essential for photographers requiring high clarity and smooth images.
The stainless steel construction ensures durability in all climatic conditions, resisting rust in humid environments and maintaining performance through extreme temperature changes.
Designed for user convenience, GR Series Isolators feature quick installation without specialized tools and a modular design for easy maintenance and component replacement.
Xi'an Hoan's GR Series Wire Rope Isolators are the preferred choice for professional photographers and videographers across various Filming environments, offering superior stability, durability, and adaptability.
GR6 Series Performance Data (Vertical)
| No. |
Model |
Max Static Load (N) |
Max Deflection (mm) |
Kv(Vibration) (KNm) |
Ks(shock) (KNm) |
| 1 |
GR6-142D-A |
142 |
22.1 |
32 |
16 |
| 2 |
GR6-93D-A |
93 |
29.5 |
20 |
9.6 |
| 3 |
GR6-67D-A |
67 |
37.6 |
15 |
5.3 |
| 4 |
GR6-36D-A |
36 |
51.6 |
7.9 |
2.6 |
GR6 Series Performance Data (Horizontal)
| No. |
Model |
Max Static Load (N) |
Max Deflection (mm) |
Kv(Vibration) (KNm) |
Ks(shock) (KNm) |
| 1 |
GR6-142D-A |
40 |
22.9 |
16 |
7.9 |
| 2 |
GR6-93D-A |
33 |
30.5 |
9.6 |
5.3 |
| 3 |
GR6-67D-A |
22 |
38.1 |
7.9 |
2.8 |
| 4 |
GR6-36D-A |
13 |
53.3 |
3.5 |
1.2 |
